Carrier 550RT Water-Cooled Centrifugal Chiller 19XRV5054C29LBG52 (New)in stock
Carrier 19XRV5054C29LBG52 high-efficiency water-cooled centrifugal chiller, manufactured in March 2024 by Shanghai Yileng Carrier. Nominal cooling capacity 1,934.2 kW (≈550 RT), rated power 306.5 kW, COP 6.31 and IPLV up to 8.42 — China National Class 1 energy efficiency. Charged with R134a refrigerant (704 kg). Powered by 380V/3Ph/50Hz. Unit weight 10,654 kg.
Description
| Item | Specification |
|---|---|
| Brand | Carrier |
| Unit Type | Centrifugal Water-Cooled Chiller |
| Unit Model | 19XRV5054C29LBG52 |
| Energy Label Model | 19XRV5054C29LBG52CD240001004 |
| Serial No. | 240200720 |
| Manufacturing Date | March 2024 |
| Energy Efficiency Grade | China National Class 1 |
| Nominal Cooling Capacity | 1,934.2 kW (550 RT) |
| User Condition Cooling Capacity | 1,934.2 kW |
| Nominal Input Power | 306.5 kW |
| User Condition Input Power | 347.6 kW |
| COP (Nominal) | 6.31 |
| COP (User Condition) | 5.56 |
| IPLV | 8.42 |
| Power Supply | 380V, 3Ph, 50Hz |
| Refrigerant | R134a |
| Refrigerant Charge | 704 kg |
| Unit Total Weight | 10,654 kg |
| Overall Dimensions (L×W×H) | 4,400 × 2,638 × 2,419 mm |
| Nominal Chilled Water Outlet Temp | 7.00 °C |
| User Condition Chilled Water Outlet Temp | 6.00 °C |
| Nominal Cooling Water Inlet Temp | 30.00 °C |
| User Condition Cooling Water Inlet Temp | 32.00 °C |
| Executive Standard | GB/T 18430.1-2007 |
| Energy Label Standard | GB 19577-2015 |
| Manufacturer | Shanghai Yileng Carrier Air-Conditioning Equipment Co., Ltd. |
| Compressor Model | 02XRCLBG525 |
| Compressor Mfg No. | 02XRC29LBG525VSC |
| Compressor Serial No. | 0624Z09347 |
| Compressor Test Pressure (Gage) | 232 PSI / 1,600 kPa |
| Compressor Max Working Pressure (Gage) | 185 PSI / 1,276 kPa |
| Compressor Locked Rotor Amps (Delta) | 3,228 A |
| Compressor Locked Rotor Amps (Wye) | 1,098 A |
| Compressor Overload Trip Amps | 680 A |
| Condenser Product Model | FC-E54NA2F10FC |
| Condenser Product No. | B24-193 |
| Condenser Pressure Vessel Class | II |
| Condenser Net Weight | 2,925 kg |
| Condenser Heat Exchange Area | 140.2 m² |
| Condenser Manufactured Date | 26/02/2024 |
| Condenser Tube Side Design Pressure | 1.0 MPa |
| Condenser Tube Side Design Temp | 50 °C |
| Condenser Tube Side Test Pressure | 1.3 MPa (hydraulic) |
| Condenser Tube Side Medium | Water |
| Condenser Tube Side Main Material | T2 (copper) |
| Condenser Shell Side Design Pressure | 1.3 MPa |
| Condenser Shell Side Design Temp | 50 °C |
| Condenser Shell Side Test Pressure | 1.43 MPa (pneumatic) |
| Condenser Shell Side Medium | R134a |
| Condenser Shell Side Main Material | Q345R |
| Condenser Equip. Code | 215031039202400675 |
| Evaporator Product Model | FE-B50NA2F10EN |
| Evaporator Product No. | B24-192 |
| Evaporator Pressure Vessel Class | II |
| Evaporator Net Weight | 2,545 kg |
| Evaporator Heat Exchange Area | 93.6 m² |
| Evaporator Manufactured Date | 26/02/2024 |
| Evaporator Tube Side Design Pressure | 1.0 MPa |
| Evaporator Tube Side Design Temp | 50 °C |
| Evaporator Tube Side Test Pressure | 1.3 MPa (hydraulic) |
| Evaporator Tube Side Medium | Water |
| Evaporator Tube Side Main Material | T2 (copper) |
| Evaporator Shell Side Design Pressure | 1.3 MPa |
| Evaporator Shell Side Design Temp | 50 °C |
| Evaporator Shell Side Test Pressure | 1.43 MPa (pneumatic) |
| Evaporator Shell Side Medium | R134a |
| Evaporator Shell Side Main Material | Q345R |
| Evaporator Equip. Code | 215031039202400674 |
