Carrier 30XW1261 Water-cooled Chiller
This is a Carrier 30XW1261‑model water‑cooled screw chiller, manufactured in July 2017. Rated cooling capacity is 1267.0 kW, input power 215.3 kW, COP 5.88, IPLV 6.70. It uses R134a refrigerant, operates on 380V‑50Hz‑3‑phase power. Total unit weight is 7296kg
Description
Product Introduction
This is a Carrier‑brand 30XW1261 water‑cooled chiller, produced in July 2017
1. Core cooling‑related parameters
Nominal cooling capacity reaches 1267.0kW, input power 215.3kW under GB standard working condition. The chilled‑water outlet temperature is set at 7℃. The water flow rate of chilled water is 217.9m³/h, cooling‑water flow is 271.2m³/h. Rated working current is 359.5A, power supply is 380V, 50Hz, three‑phase industrial power supply, which fits most industrial and commercial power‑supply standards.
2. Energy‑saving performance
Its COP value is 5.88, IPLV reaches 6.70. Excellent part‑load energy‑saving performance cuts long‑term‑running electricity‑cost for shopping malls, factories and large‑size office buildings. It adopts R134a eco‑friendly refrigerant, with total refrigerant charge 300kg, stable chemical property, non‑ozone‑depleting. The whole‑unit weight is 7296kg, solid structure and long service life.
3. Application scope
The chiller suits central‑air‑conditioning cooling for shopping malls, industrial plants, hotels, hospitals and commercial complexes. The used unit has passed complete running tests, no hidden faults, stable performance and low later‑stage maintenance cost.
Hot Tags: carrier 30xw1261 water-cooled chiller, China carrier 30xw1261 water-cooled chiller suppliers, factory, 400 TR Carrier 30XW1402S Water Cooled Chiller, Carrier 30HXC165A Water Cooled Chiller, dm120 york, outdoor chiller, water tank chiller, york yr chiller
