Carrier 550RT Water Cooled Chiller 19XR404038HUGU52 (Used)in stock

Carrier 550RT Water Cooled Chiller 19XR404038HUGU52 (Used)in stock

Model : 19XR404038HUGU52-SR3N091 The Carrier 19XR series represents the pinnacle of high-capacity, water-cooled centrifugal chiller technology. Designed for demanding commercial and industrial applications, it delivers exceptional energy efficiency, reliable performance, and environmental responsibility.

Description

Item Specification
Machine Type Water-Cooled Centrifugal Liquid Chiller
Unit Model 19XR404038HUGU52
Energy Efficiency Model 19XR404038HUGU52-SR3N091
Serial Number XR3S1383
Date of Manufacture June 2017 (2017.06)
Refrigerant R134a
Refrigerant Charge 483 kg
Unit Weight 7,338 kg
Power Supply 380 V / 3 Ph / 50 Hz
Dimensions (L × W × H) 4,365 × 1,908 × 2,153 mm
Standard Complied GB/T 18430.1-2007
IPLV 6.31
Cooling Capacity (Nominal) 1,934.0 kW ( 550 RT)
Cooling Capacity (User Condition) 1,934.0 kW
Input Power - Cooling (Nominal) 336.1 kW
Input Power - Cooling (User Condition) 337.5 kW
COP (Nominal) 5.75
COP (User Condition) 5.73
Leaving Chilled Water Temp. (Nominal) 7.00 °C
Leaving Chilled Water Temp. (User Condition) 7.00 °C
Entering Condenser Water Temp. (Nominal) 30.00 °C
Entering Condenser Water Temp. (User Condition) 30.00 °C

Carrier Centrifugal Chiller is a four-dimensional innovative unit that integrates high efficiency,environmental protection, intelligence and reliability. It is the first choice for low-carbon transformation of high-end buildings, especially suitable for scenarios that require stable cooling throughout the year and focus on long-term operating costs.



19XR is a centrifugal chiller engineered for comfort cooling, process cooling, and heating applications. It utilizes proven technology optimized for chlorine-free refrigerants, offering the most cost-effective and reliable solution for today's HVAC needs .



The 19XR series is designed to achieve industry-leading energy efficiency. With the 19XRV variable-speed option, the chiller can reach exceptional IPLV ratings  low , significantly reducing annual energy costs .



The 19XR chiller is compatible with chlorine-free refrigerants, ensuring a sustainable approach to cooling without compromising performance .

Refrigerants: The unit is designed to work with R-134a, R-513A, and R-515B
