Trane Air Cooled Heat Pump Chiller

Name: China Discount Trane Air Cooled Heat Pump Chiller Suppliers Factory - Chvac Machinery
Brand: Chvac
SKU: 258776536

The Trane CXAJ Series Air Cooled Heat Pump Chiller provide an efficient and reliable solution for both cooling and heating needs, ideal for light commercial and domestic applications. Here’s a breakdown of the key features and specifications:

Send Inquiry

Download

Description

Features

In Stock Ready To Ship

1. High-Efficiency Scroll Compressor:

Utilizes a high-efficiency parallel scroll compressor and multi-refrigeration circuit design.
The system allows for multi-stage energy regulation based on load, enhancing efficiency and performance.

2. Flexible Heat Pump Function:

The unit supports both cooling and heating, providing flexibility to switch between modes depending on the season and environmental conditions, making it versatile year-round.

3. Environmentally Friendly Refrigerants

The CXAJ series Air Cooled Heat Pump Chiller uses R-410A, a refrigerant with low global warming potential (GWP). This makes the unit eco-friendly and compliant with international environmental standards, contributing to sustainability.

4. Intelligent Control System

Features advanced control systems with remote monitoring and management capabilities. The system can be operated through mobile devices or computers for:

Temperature regulation.
Monitoring operating status.
Fault diagnosis.

Includes Trane's Mini-ICS centralized controller, a large LCD screen, and a user-friendly interface for ease of operation.

5. Easy Installation

The water system utilizes a parallel design, which reduces water pressure drops and consequently lowers the power consumption of the pump.
The uniform size of installation nozzles ensures a neat and aesthetically pleasing setup.

Model	CXAJ0605A1NSCRA (other models also available)
Cooling Capacity	Available in three modules	45 kW, 65 kW, and 130 kW.
	Options for both heat pump and single cooler configurations.
	Modular combination allows customization based on specific needs.
Refrigerant Type	Environmentally friendly R-410A.
Compressor Model	As per parameter table (specific compressor types vary depending on the model).

Application

The Trane CXAJ/CGAJ Series Air Cooled Heat Pump Chiller is suitable for a wide range of applications, including:

Commercial Buildings

Offices, shopping malls, etc.

Industrial Facilities

Production plants, storage centers, etc.

Medical Institutions

Hospitals, clinics, etc.

Data Centers

Server rooms, cloud computing centers, etc.

parameter

High-efficiency Model (H type)
Model				CXAJ065	CXAJ130	CGAJ065	CGAJ130
Cooling	Rated Cooling Capacity		kw	65	130	65	130
	Rated Input Power		kw	21	40.9	21	40.9
	Rated Operating Current		A	40.5	78	40.5	78
Heating	Rated Heating Capacity		kw	67	137	-	-
	Rated Input Power		kw	21.5	40	-	-
	Rated Operating Current		A	41	71	-	-
MAX Operating	Max. Input Power		kw	29.2	57.2	29.2	57.2
MAX Operating	Max.Current		A	55	98.2	55	98.2
Compressor	Category	Hermetic scroll
	No.		Pieces	2	4	2	4
	Rated Cooling Power		kw	9.2	9.2	9.2	9.2
	Rated Cooling Current		A	18	18	18	18
	Rated Heating Power		kw	9.1	9.1	-	-
	Rated Heating Current		A	18	18	-	-
Refrigerant	Category	R410A
Refrigerant	Charge		kg	15	15*2	15	15*2
Water Side	Category of Heat Exchanger		High-effciency shell-tube heat exchanger
	Rated Water Flow		CMH	11.2	22.4	11.2	22.4
	Water Pressure Drop		kPa	60	70	60	70
	Connections		mm	DN125	DN125	DN125	DN125
Air side	Category of Heat Exchanger		High-eficiency fin-coil heat exchanger
	Fan No.		Pieces	2	2	2	2
	Rated Input Power of Fan		kw	0.75	1.5	0.75	1.5
	Rated Current of Fan		A	2.1	3.96	2.1	3.96
	Air Flow		CMH	12000	20000	12000	20000
Unit	Power Supply		V/PHHz	380/3N~/50
	Noise		dB(A)	69	70	69	70
	Net Weight		Kg	730	1150	730	1150
	Operating Weight		Kg	800	1250	800	1250
Dimension	Length		mm	2145	2400	2415	2400
	Width		mm	1000	1200	1000	1200
	Height		mm	2155	2380	2155	2380
1. The cooling capacity is measured in the conditions of water outlet at 7°c and air inlet at the ambient temperaturof 35°c 2.The heating capacity is measured in the conditions of water outlet at 45°c and air inlet at the ambient dry bulbtemperature of 7°c and the wet bulb temperature of 6°C.

Standard-efficiency Model (N type)
Model				CXAJ065	CXAJ130	CGAJ065	CGAJ130
Cooling	Rated Cooling Capacity		kw	65	130	65	130
	Rated Input Power		kw	21.6	43.2	21.6	43.2
	Rated Operating Current		A	42	81	42	81
Heating	Rated Heating Capacity		kw	67	137	-	-
	Rated Input Power		kw	21	41	-	-
	Rated Operating Current		A	41.5	74	-	-
MAX Operating	Max. Input Power		kw	29.2	60	29.2	60
MAX Operating	Max.Current		A	55	120	55	120
Compressor	Category	Hermetic scroll
	No.		Pieces	2	2	2	4
	Rated Cooling Power		kw	10.1	20	10.1	20
	Rated Cooling Current		A	19.2	38	19.2	38
	Rated Heating Power		kw	9.5	19	-	-
	Rated Heating Current		A	18.5	34	-	-
Refrigerant	Category	R410A
Refrigerant	Charge		kg	13	12.5*2	13	12.5*2
Water Side	Category of Heat Exchanger		High-effciency shell-tube heat exchanger
	Rated Water Flow		CMH	11.2	22.4	11.2	22.4
	Water Pressure Drop		kPa	60	70	60	70
	Connections		mm	DN125	DN125	DN125	DN125
Air side	Category of Heat Exchanger		High-eficiency fin-coil heat exchanger
	Fan No.		Pieces	2	2	2	2
	Rated Input Power of Fan		kw	0.75	1.5	0.75	1.5
	Rated Current of Fan		A	2.1	3.96	2.1	3.96
	Air Flow		CMH	12000	20000	12000	20000
Unit	Power Supply		V/PHHz	380/3N~/50
	Noise		dB(A)	69	70	69	70
	Net Weight		Kg	710	1050	710	1050
	Operating Weight		Kg	780	1150	780	1150
Dimension	Length		mm	2145	2400	2145	2400
	Width		mm	1000	1200	1000	1200
	Height		mm	2155	2380	2155	2380

The CXAJ Series Air Cooled Heat Pump Chiller offers a versatile, energy-efficient, and environmentally friendly solution for both cooling and heating needs. It is particularly ideal for commercial, industrial, and medical facilities, as well as data centers. Its intelligent controls, flexible performance, and easy installation make it a preferred choice for anyone seeking a reliable and sustainable HVAC system. If you're involved in a new project or upgrading an existing facility, Trane's professional services can provide you with tailored, efficient solutions.
