Used Carrier 23XRV4040NRVAA90 Variable‑Speed Centrifugal Chiller

Used Carrier 23XRV4040NRVAA90 Variable‑Speed Centrifugal Chiller

Model No.: 23XRV4040NRVAA90 Serial No.: RVP1074

This is Carrier high‑efficiency variable‑speed magnetic‑bearing centrifugal chiller, fitted with original Carrier controller. It delivers outstanding energy‑saving performance under partial‑load, featuring low vibration and low noise. Widely used for shopping malls, high‑rise office buildings, hotels, hospitals and industrial process cooling projects. The unit has been fully inspected, leak‑tested and electrically tested. Cooling tower, chilled‑water pump and cooling‑water pump are required for operation.

✅ Technical Data

Power Supply: 380V / 3‑Phase / 50Hz

Locked Rotor Amps: 414.6 A

Overload Trip Amps: 425 A

Max Fuse / Circuit Breaker: 800 A

Min Supply Circuit Ampacity: 518 A

Rated Input Kilowatts: 260 kW

Motor Rated Load kW: 253.9 kW

Compressor Motor Power: 310.5 kW

Rated Line Amps: 414.6 A

Motor Rated Load Amps: 393.6 A

Motor Maximum Amps: 440 A

Motor RPM: 2722 RPM

Compressor 100% Speed Frequency: 91.5 Hz

Inverter PWM Frequency: 4 kHz

Oil Pump: 115V, 1.48A

Oil Sump Heater: 115V, 4.35A, 500W

Oil Vaporizer Heater: 115V,13.04A,1500W
